316L Ss-1vs4 Swagelok Type Manual Stainless Needle Valve 5000psi 3/8in for Labs

1 / 5

316L Ss-1vs4 Swagelok Type Manual Stainless Needle Valve 5000psi 3/8in for Labs

Still deciding? Get samples of $ !

Request Sample

Send Inquiry

Product Description

Basic Information

Model NO.

ED11A1115

Temperature

Ordinary Temperature

Connection

Thread

Valve Seat

Double-Seat

Structure

Diaphragm

Material

Stainless Steel

Inlet Pressure P1

Max. 100 Bar

Outlet Pressure P2

2/4/10/20/50 Bar

Diaphragm

Hastelloy® C276

Leak Rate (Atm)

1×10-8 Mbar I/S He

Leak Rate (Seat)

1×10-6 Mbar I/S He

Flow Capacity

CV=0.07

Gas Panels

Yes

Gas & Oil

Yes

Acid Compatible

Yes

Specification

Dual-stage

Product Description

A specialized Ultra High Purity (UHP) Gas and Chemical Delivery system component, manufacturing High Purity Regulators and Diaphragm Valves for specialty, flammable, and industrial gas flows.

Core Features

◈Live-loaded packing system

◈Vee stem, regulating stem, and soft-seat optional

◈Compact design for space-saving installation

◈Panel mounting capability

◈Straight, angle, and cross flow patterns

◈Working pressure up to 5000 psig (345 bar)

Technical Data - JNV Series

Specification	Details
Valve Type	High Purity High Pressure Stainless Steel Needle Valve
Inlet pressure P1	Max. 345 bar
Material	Stainless Steel SS 316L
Seat Material	PCTFE
Filter	316 Stainless Steel
Temperature Range	-54ºC to +232ºC
Leak Rate	0.1 cc/min
Surface Finish	Electropolished to Ra < 5 µin (0.127 µm)

Enhanced Flow Capacity: Cv up to 1.7 enabling efficient chemical delivery.

Ordering Information & Applications

Primary Applications:

Semiconductor manufacturing & Thin-film coating
Oil & Gas industrial processes
Laboratory Pressure Control & High Pressure Sampling
UHP gas distribution in cleanrooms

Factory Capability & Related Solutions

Available Product Range:

HP Gas Regulators & UHP Diaphragm Valves
Tube Fittings & Stainless Steel Tee Fittings
UHP Pressure Gauges & Check Valves
Gas Cabinets & Cylinder Accessories

Frequently Asked Questions (FAQ)

What is the maximum working pressure for these needle valves?

The JNV Series needle valves are designed to handle high-pressure environments with a maximum inlet pressure of up to 5000 psig (345 bar).

Are these valves suitable for ultra-high purity (UHP) gas delivery?

Yes, the valves feature an electropolished surface finish (Ra < 5 µin) to minimize particle generation and adsorption, making them ideal for semiconductor and cleanroom applications.

What materials are used for the diaphragm and seats?

We use high-grade materials including Hastelloy® C276 or 316L stainless steel for diaphragms and PCTFE for the valve seats to ensure chemical compatibility and durability.

Can the valves operate in high-temperature environments?

The JNV Series has a broad temperature tolerance, operating reliably from -54ºC up to +232ºC, suitable for atomic layer deposition (ALD) and other thermal processes.

Is customization available for small order quantities?

Yes, we provide customization services for small quantities to meet specific laboratory or industrial requirements, including various flow patterns and connection types.

What is the leak rate performance of these valves?

The valves offer exceptional sealing performance with a leak rate to atmosphere of 1×10-8 Mbar I/S He and via the seat of 1×10-6 Mbar I/S He.

Product Detail

316L Ss-1vs4 Swagelok Type Manual Stainless Needle Valve 5000psi 3/8in for Labs

Product Description
