A wafer butterfly valve is a type of quarter-turn valve that regulates the flow of fluids in a pipeline. It's called a "wafer" valve due to its slim, wafer-like profile, allowing it to be installed between two flanges without the need for additional flange bolts.
The valve consists of a disc or "butterfly" that rotates around a central shaft. This disc is typically made of metal or a resilient material such as rubber or PTFE. The valve body features a slim profile, facilitating easy installation between flanges.
Open Position: The valve disc rotates parallel to the flow direction, allowing fluid to pass through with minimal obstruction. The disc is mounted centrally and supported by a shaft.
Flow Control: The valve disc is rotated using an actuator (manual, electric, pneumatic, or hydraulic). As the disc rotates, it gradually obstructs the flow to reduce the flow rate.
| Part Name | Materials Available |
|---|---|
| Body | Ductile Iron |
| Seat | EPDM / BUNA / PTFE |
| Disc | Ductile Iron / 316 Stainless Steel / Bronze |
| Bushing | PTFE |
| O-Ring | EPDM / BUNA |
| Taper Pin | 316 Stainless Steel |
| Stem | 416 Stainless Steel |
A: They are widely used for industrial applications, water treatment systems, fire protection, and household liquid control systems.
A: The wafer design is lightweight and compact, allowing the valve to be clamped between pipe flanges, which saves space and simplifies installation.
A: Yes, these soft-sealing center line butterfly valves are designed to provide zero leakage tight shutoff performance.
A: Our valves are manufactured according to international standards including API609, EN593, BS5155, and ISO5211.
A: We offer various seat materials to suit different mediums, including NBR, EPDM, PTFE, and Silicone.
A: The standard delivery time is between 15 to 25 days depending on the specification and quantity ordered.
