Model NO.
2 1/16"~7 1/16"
Operation Pressure
Atmospheric Pressure
Specification Level
Psl1, Psl2, Psl3, Psl3g, Psl4
Performance Levels
Pr1, Pr2
Material Level
AA, Bb, Cc, Dd, Ee, FF, Hh
Production Capacity
50000 Sets/Year
⚡
Full Bore Design: Effectively eliminates pressure drop and vortex, reducing flushing by solid particles in the fluid.
⚡
Reduced Torque: Special seal type design significantly reduces switching torque for easier operation.
⚡
Metal-to-Metal Seal: Reliable sealing between valve body and bonnet, as well as gate and seat.
⚡
Hard Alloy Coating: Gate surface features supersonic spray coating and seat ring with hard alloy or stainless coating for high anti-corrosive and wear resistance.
⚡
Stability: Seat ring is secured by a fixed plate for excellent performance stability.
⚡
Back Seal Design: Allows for easy packing replacement even under pressure.
⚡
Maintenance Friendly: Equipped with a sealing grease injection valve to improve lubrication and sealing performance.
⚡
Actuator Options: Can be equipped with pneumatic or hydraulic actuators upon requirement.
Frequently Asked Questions
What are the available sizes for the API 6A FC Gate Valve?
The valve comes in several nominal diameters including 2-1/16, 2-9/16, 3-1/16, 4-1/16, 5-1/8, and 7-1/16.
What pressure ratings does this valve support?
It is designed to handle a wide range of working pressures: 2000PSI, 3000PSI, 5000PSI, 10000PSI, and up to 15000PSI.
Is the valve suitable for H2S and CO2 environments?
Yes, the working medium includes oil, natural gas, mud, and gases containing H2S and CO2, making it highly versatile for harsh environments.
What is the advantage of the full bore design?
The full bore design effectively eliminates pressure drops and vortexes, which helps in slowing down the erosion/flushing caused by solid particles in the fluid.
Can the stem packing be replaced while under pressure?
Yes, the valve features a back seal design for the stem, which allows for the safe and easy replacement of packing even when the valve is under pressure.
What automation options are available for these valves?
Depending on your specific operational requirements, we can equip the valves with either pneumatic or hydraulic actuators.
